| Focus |
|
|
| Focus Type |
Auto and Manual Focus
|
|
| Focus Mode |
Continuous-Servo AF, Manual Focus, Single-Servo AF
|
|
| Autofocus Points |
Phase Detection: 779
|
|
| Autofocus Sensitivity |
-4 to +18 EV |
|
| |
|
|
| Viewfinder |
|
|
| Type |
Electronic (OLED)
|
|
| Size |
0.5" |
|
| Resolution |
3,680,000 Dot
|
|
| Eye Point |
21 mm
|
|
| Coverage |
100%
|
|
| Magnification |
Approx. 0.8x
|
|
| Diopter Adjustment |
-4 to +2 |
|
| |
|
|
| Imaging |
|
|
| Lens Mount |
Micro Four Thirds
|
|
| Sensor Resolution |
Actual: 26.52 Megapixel
Effective: 25.21 Megapixel (5776 x 4336) |
|
| Image Sensor |
17.3 x 13 mm (Four Thirds) MOS |
|
| Sensor Crop (35mm Equivalent) |
Crop Factor: 2x
*Additional Crop Occurs in Select Video Modes |
|
| Image Stabilization |
Sensor-Shift, 5-Axis
|
|
| Built-In ND Filter |
No |
|
| Capture Type |
Stills & Video |
|
| |
|
|
| Exposure Control |
|
|
| Shutter Type |
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
|
|
| Shutter Speed |
Electronic Shutter: 1/32000 to 60 Seconds, Electronic Front Curtain Shutter: 1/2000 to 60 Seconds, Mechanical Shutter: 1/8000 to 60 Seconds |
|
| Bulb/Time Mode |
Bulb Mode (Up to 30 Minutes)
|
|
| ISO/Gain Sensitivity |
Photo: Native: 100 to 25,600 (50 to 25,600 Extended)
Video: Native: 100 to 12,800 (50 to 12,800 Extended) |
|
| Metering Method |
Center-Weighted Average, Highlight Weighted, Multiple, Spot
|
|
| Exposure Modes |
Aperture Priority, Auto, Manual, Program, Shutter Priority
|
|
| Exposure Compensation |
-5 to +5 EV (1/3 EV Steps)
|
|
| Metering Range |
0 to 18 EV
|
|
| White Balance |
2500 to 10,000K
Presets: AWB, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4 |
|
| Continuous Shooting |
Up to 75 fps at Maximum Resolution for up to 200 Frames (JPEG, Raw)
|
|
| Interval Recording |
Yes |
|
| Self-Timer |
2/10-Second Delay |
|
| |
|
|
| Still Image Capture |
|
|
| Aspect Ratio |
1:1, 3:2, 4:3, 16:9
|
|
| Image File Format |
JPEG, Raw |
|
| |
|
|
| Video Capture |
|
|
| |
|
|
| Internal Recording |
H.264 ALL-Intra/H.265 Long GOP 4:2:2/4:2:0 8/10-Bit
5760 x 4320 at 23.98/24.00/25/29.97 fps [200 Mb/s]
4352 x 3264 at 47.95/48.00/50/59.94 fps [300 Mb/s]
5728 x 3024 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94 fps [200 to 300 Mb/s]
4096 x 2160 at 23.98/24.00/25/29.97/47.95/50/59.94/100/120 fps [150 to 600 Mb/s]
3840 x 2160 at 23.98/24.00/25/29.97/47.95/50/59.94/100/120 fps [72 to 600 Mb/s]
1920 x 1080 at 23.98/24.00/25/29.97/47.95/50/59.94/100/120/200/240/300 fps [20 to 400 Mb/s]
ProRes 422/ProRes 422 HQ
1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [121 to 454 Mb/s] |
|
| Video Output |
4:2:2 10-Bit via USB
5728 x 3024 at 23.98/24.00/25/29.97 fps
4096 x 2160 at 23.98/24.00/25/29.97/47.95/50/59.94 fps
3840 x 2160 at 23.98/24.00/25/29.97/47.95/50/59.94 fps
1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/200/240 fps |
|
| Fast-/Slow-Motion Support |
Yes |
|
| Gamma Curve |
HDR-HLG, Panasonic V-Gamut, Panasonic V-Log
|
|
| Recording Limit |
No |
|
| IP Streaming |
No |
|
| Built-In Microphone |
Stereo |
|
| Audio Recording |
MOV: 2-Channel 24-Bit 48 kHz LPCM Audio, MP4: 2-Channel 16-Bit 48 kHz AAC Audio |
|
| |
|
|
| Interface |
|
|
| Media/Memory Card Slot |
Dual Slot: SD/SDHC/SDXC (UHS-II)
|
|
| Video I/O |
1x HDMI Output
|
|
| Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
1x 1/8" / 3.5 mm TRS Stereo Microphone Input |
|
| Power I/O |
1x USB-C Input
|
|
| Other I/O |
1x 2.5 mm Sub-Mini Remote Input
1x USB-C (USB 3.2 / 3.1 Gen 2) Data Output (Shared with Power Input) |
|
| Wireless |
2.4 / 5 GHz Wi-Fi 5 (802.11ac), Bluetooth 5.0
|
|
| Mobile App Compatible |
Yes: Android & iOS
App Name: LUMIX Sync
Functionality: Access Stored Files, Adjust Settings, Firmware Update, Remote Control |
|
| Global Positioning (GPS, GLONASS, etc.) |
GPS *Via Connected Smartphone |
|
| |
|
|
| Monitor |
|
|
| Display Size |
3" |
|
| Resolution |
1,840,000 Dot
|
|
| Display Type |
Articulating Touchscreen LCD |
|
| |
|
|
| Flash |
|
|
| Built-In Flash/Light |
No |
|
| Maximum Sync Speed |
1/250 Second
|
|
| Flash Compensation |
-3 to +3 EV (1/3 EV Steps)
|
|
| Dedicated Flash System |
TTL |
|
| External Flash Connection |
Shoe Mount, Wireless |
|
| |
|
|
| General |
|
|
| Battery |
1x DMW-BLK22 Rechargeable Lithium-Ion, 7.2 VDC, 2200 mAh (Included)
• Approx. 370 Shots |
|
| Shoe Mount |
1x Hot Shoe
|
|
| Tripod Mounting Thread |
1x 1/4"-20 Female (Bottom)
|
|
| Material of Construction |
Magnesium Alloy
|
|
