| Focus |
|
|
| Focus Type |
Auto and Manual Focus
|
|
| Focus Mode |
Automatic, Continuous-Servo AF, Manual Focus
|
|
| Autofocus Points |
Autofocus Points |
|
| |
|
|
| Viewfinder |
|
|
| Type |
Electronic (OLED)
|
|
| Resolution |
5,760,000 Dot
|
|
| Eye Point |
21 mm
|
|
| Coverage |
100% |
|
| Magnification |
Approx. 0.78x
|
|
| Diopter Adjustment |
-4 to +2 |
|
| |
|
|
| Imaging |
|
|
| Lens Mount |
L-Mount
|
|
| Sensor Resolution |
Actual: 26.8 Megapixel
Effective: 24.1 Megapixel |
|
| Image Sensor |
35.8 x 23.8 mm (Full-Frame) CMOS
|
|
| Sensor Crop (35mm Equivalent) |
Crop Factor: 1x
*Additional Crop Occurs in Select Video Modes |
|
| Image Stabilization |
Sensor-Shift, 5-Axis
|
|
| Built-In ND Filter |
No |
|
| Capture Type |
Stills & Video |
|
| |
|
|
| Exposure Control |
|
|
| Shutter Type |
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
|
|
| Shutter Speed |
Electronic Front Curtain Shutter: 1/2000 to 60 Seconds
Mechanical Shutter: 1/8000 to 60 Seconds |
|
| Bulb/Time Mode |
Bulb Mode (Up to 30 Minutes)
|
|
| ISO/Gain Sensitivity |
Dual Base: 100 / 800*
Native: 100 to 51,200 (50 to 204,800 Extended)
*Base ISO Is Dependent on Selected Color Space |
|
| Metering Method |
Center-Weighted Average, Highlight Weighted, Multi-Zone, Multiple, Spot |
|
| Exposure Modes |
Aperture Priority, Auto, Manual, Program, Shutter Priority
|
|
| Exposure Compensation |
-3 to +5 EV (1/3 EV Steps)
|
|
| Metering Range |
0 to 18 EV
|
|
| White Balance |
2500 to 10,000K
Presets: AWB, Cloudy, Color Temperature Filter, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4 |
|
| Continuous Shooting |
Up to 70 fps at Maximum Resolution
|
|
| Self-Timer |
2/10-Second Delay |
|
| |
|
|
| Still Image Capture |
|
|
| Aspect Ratio |
1:1, 2:1, 3:2, 4:3, 16:9, 65:24
|
|
| Image File Format |
HEIF, JPEG, Raw |
|
| |
|
|
| Video Capture |
|
|
| Internal Recording |
ProRes RAW/ProRes RAW HQ
4800 x 3600 at 23.98/24.00/25/29.97 fps [1.9 Gb/s]
5760 x 3040 at 23.98/24.00/25/29.97 fps [4.2 Gb/s]
3328 x 2496 at 23.98/24.00/29.97/59.94 fps [1.8 Gb/s]
4096 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps [1.9 Gb/s]
3840 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps
4096 x 1728 at 23.98/24.00/25/29.97/50/59.94 fps [4.2 Gb/s]
1920 x 1080 at 23.98/24.00/29.97/50/59.94/100/120 fps
H.264 ALL-Intra/H.264 Long GOP 4:2:2 10-Bit
3328 x 2496 at 23.98/29.97/47.95/59.94 fps [800 Mb/s]
4096 x 2160 at 23.98/29.97/47.95/59.94 fps [800 Mb/s]
3840 x 2160 at 23.98/29.97/47.95/59.94 fps [800 Mb/s]
4096 x 1728 at 23.98/29.97/47.95/59.94 fps [800 Mb/s]
1920 x 1080 at 23.98/29.97/47.95/59.94/120/240 fps [800 Mb/s]
H.265 Long GOP 4:2:0 8/10-Bit
5952 x 3968 at 23.98/24.00/25/29.97 fps [200 Mb/s]
4800 x 3600 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94 fps [300 Mb/s]
5088 x 3392 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94 fps [300 Mb/s]
5888 x 3312 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94 fps [300 Mb/s]
5760 x 3040 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94 fps [300 Mb/s]
5952 x 2512 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94 fps [300 Mb/s]
3328 x 2496 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94/120 fps
DCI 4K (4096 x 2160) at 23.98/25/29.97/47.95/50/59.94/96/120 fps [300 Mb/s]
3840 x 2160 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94/120 fps [300 Mb/s]
4096 x 1728 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94/96/100/120 fps [300 Mb/s]
1920 x 1080 at 23.98/24.00/25/29.97/47.95/48.00/59.94/100/120/200/240 fps [800 Mb/s] |
|
| Video Output |
4:2:0 10-Bit via HDMI
4096 x 2160 at 120 fps
1920 x 1080 at 59.94 fps |
|
| Fast-/Slow-Motion Support |
Yes |
|
| Recording Limit |
No |
|
| IP Streaming |
RTMPS
1920 x 1080 at 59.94p (8.0 Mb/s) |
|
| Built-In Microphone |
Stereo |
|
| Audio Recording |
MOV: 2-Channel 24-Bit 48 kHz LPCM Audio |
|
| |
|
|
| Interface |
|
|
| Media/Memory Card Slot |
Slot 1: CFexpress Type B
Slot 2: SD/SDHC/SDXC |
|
| Video I/O |
1x HDMI Output
|
|
| Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
1x 1/8" / 3.5 mm TRS Stereo Microphone Input |
|
| Power I/O |
1x USB-C Input
|
|
| Other I/O |
1x USB-C Data Output (Shared with Power Input)
|
|
| Wireless |
5 GHz Wi-Fi 5 (802.11ac)
|
|
| Mobile App Compatible |
Yes: Android & iOS
App Name: Lumix Lab |
|
| Global Positioning (GPS, GLONASS, etc.) |
GPS
*Via Connected Smartphone |
|
| |
|
|
| Monitor |
|
|
| Display Size |
3" |
|
| Resolution |
1,840,000 Dot
|
|
| Display Type |
Free-Angle Tilting Touchscreen LCD |
|
| |
|
|
| Flash |
|
|
| Built-In Flash/Light |
No |
|
| Flash Modes |
Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction |
|
| Maximum Sync Speed |
1/250 Second
|
|
| Flash Compensation |
-3 to +3 EV (1/3 EV Steps) |
|
| Dedicated Flash System |
TTL |
|
| External Flash Connection |
Shoe Mount |
|
| |
|
|
| General |
|
|
| Battery |
1x Rechargeable Lithium-Ion, 7.2 VDC, 2200 mAh (Included)
|
|
| Shoe Mount |
1x Hot Shoe |
|
| Tripod Mounting Thread |
1x 1/4"-20 Female (Bottom)
|
|
